5) 9 inch Mitsubishi LCD panel

Brand: Mitubishi Model: AA090TB01
Size: 9 inch Lattice: R.G.B. Vertical Stripe
Pixel number: 1280×3 (H)×768 (V) Contrast:   1000:1
Viewing area: 195.84 (H)×117.504 (V)  Response time: (on/off)  12/12(MS)
Outline: 219.0 (W)×136.2 (H)×9.5 (D) Pixel Pitch: 0.153 (H)×0.153 (V)
Brightness: 800(cd/m2) Backlight): LED
Viewing Angle: R/L/U/D 85/85/85/85 Surface: Anti-glare and hard-coating 3H
Weight: 330(g) Colour: 262k(6 bit/color),16.7M(8bit/color)
Interface: LVDS (6 bit/8 bit) Display mode: Normally black display
Operation temperature:   -30-80 ()
Storage temperature:   -30-80 ()
Operation Humidity: 5-95 (%RH)
Storage Humidity: 5-95 (%RH)
