10) 2.4 inch TIANMA LCD panel

Brand TIANMA Model TM024HDH49
Size 2.4 inch Type a-Si TFT-LCD ,LCD module
Pixel number 200(RGB)×320   [QVGA] Pixel RGB verticle stripes
Active area 36.72(W)×48.96(H) mm  Viewing area 111.1(W)×67.9(H) mm
Outline 42.72(W)×60.26(H) ×2.45(T) mm       Surface treatment ClearHard coating (3H)
Brightness 250 cd/m² (Typ.) contrast 500 : 1 (Typ.) [Transmission type.]
Viewing Angle 70/70/70/60 (Typ.)(CR10)   Working mode TNnormally white display, transmission type.
Best Angle of view 6 o'clock Response time 20 (Typ.)(Tr+Td) ms
Display color 262K , 53% (CIE1931)  Light source WLED  [1S3P], 20K hours, excluding drive
Working frequency 60Hz  Touch screen Without
Weight TBD Application
Interface 44 pins   8/9/16/18-bit 8080 parallel port, FPC
Voltage (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC)
Operation environment Operating:  -20 ~ 70 °C; Storage: -30 ~ 80 °C
